Turbo Charger +Manifold Kit For Nissan Patrol Safari Y60 TD42 Oil Cold

Application

for Nissan Patrol Safari Y60 GR Petrol 4.2L TB42 TB42S TB42E
for Nissan Patrol Safari Y60 GR Petrol 4.5L TB45 TB45S TB45E
for Nissan Patrol Safari Y60 GR GQ Diesel Turbo Diesel 4.2L TD42
for Nissan Patrol Safari Y61 GR Diesel 4.2L TD42 TD422 TD42T3

Specification

Horse Power: Capable of Boosting Horse Power up to 400HP
Cooling Type: Oil Cooled

Turbo Details
Exhaust Inlet (Turbo Manifold) Flange: T3 T4 4 bolt Flange Patterns
Exhaust Outlet (Downpipe) Flange: 5 bolt Flange
Turbine Trim: 73
Turbine Inducer Diameter:  65.5 mm
Turbine Exducer Diameter: 55.9mm
Turbine A/R: 0.63
Compressor Trim: 44
Compressor Inducer Diameter: 50.5 mm
Compressor Exducer Diameter: 76 mm
Compressor A/R: 0.5
Bearing: Wet Float Bearing

Notice
* Please check the specifications carefully before bidding. If you are not sure about these information, please feel free to contact us
* This is an aftermarket application turbo, so modification might be required for some vehicles
* Professional installation is highly recommended (No Instruction Included)
