Name: Water Level Sensor 4-20mA 0-10V RS485 0-10M Range Hydrostatic Level Sensor Fuel Sensor For Water Oil
SKU: 1005004699873177
Availability: InStock

Water Level Sensor 4-20mA 0-10V RS485 0-10M Range Hydrostatic Level Sensor Fuel Sensor For Water Oil

$77.17 – $114.07

Ships From

Choose an option

China

Measuring Range

Choose an option

10M Range 10M Cable

1M Range 5M Cable

2M Range 5M Cable

3M Range 5M Cable

4M Range 5M Cable

5M Range 5M Cable

6M Range 6M Cable

8M Range 8M Cable

Color

Choose an option

0-10v Output

0-5v Output

4-20mA Output

rs485

Clear

Model Number: QDY30B
Brand Name: NoEnName_Null
Origin: Mainland China
Certification: CE,FCC
Model Name: QDY30A
OutPut: 4-20mA/0-5V/0-10V/RS485 Output
Material:: 316L Diaphgram 304 Stainless Steel
Shell Protection: IP68
Accuracy: 0.2%F.S
Lienarity: 0.1%
Overload Pressure: 300% F.S/10S
Long-term Stability: ±0.2?.S/y
Full load Consumption: 1W
Working Temperature: -20℃ – 60℃
Measuring Range: 0-500M

NOTES!!

This level sensor is for DC24V power supply.

$3 per meter if the length of cable exceeds 5 meters.

If you need other parameters, plz contact us.

OEM logo design is acceptable , MOQ 5 pcs !!!

Introduction

<1>.QDY30A submersible Water Level Sensor, its304 &316 stainless steel and hermetically sealed housing make it suitable for most industrial liquids and oils.

<2>. The welded housing is tested in-house via a helium leak tester to ensure proper protection. Ventilation tube in the cable automatically compensates for changes in atmospheric pressure above the tank. The conductors of the cable are also isolated from the outside environment to keep the level sensor operational for long-term use.
